AC charging wallbox

Wallbox VTEC

Charging power:

Up to 22 kW

Compatibility:

Type 2

Power modulation according to the home consumption
Fully manageable with the mobile app
OTA Updates
Leakage current control circuit >6mA (optional)
Can only charge with PV surplus (optional)
Custom graphics

Scarica la scheda tecnica

Download the datasheet

Téléchargez la fiche technique

Preuzmite tehnički list (ENG)

Request a quote

Converter kW > A

Wallbox VTEC

WallBox Series

The VTEC Wallbox is a high-profile product characterized by its painted steel body.

High quality materials ensure long life and resistance to the most aggressive environments.

The control system allows remote control and adjustment of charging. The standard version allows adjustment of charging power via internal switch while the other models connect to the app via bluetooth to allow remote control and adjustment of charging.

Mechanical resistance: IK10

Degree of protection: IP65

Housing material: Painted galvanised steel

Operating temperature: -25°C to +45°C

Storage temperature: -40°C to +60°C

Operating humidity: 5% to 95% non-condensing

Network connection: IoT GSM / WiFi

Signalling: RGB colour indicator

Meters: MID certified

Enabling payments: On request

Dimensions: 246 x 286 x 127.5 mm

Weight: 4 kg

Model	WB VTEC Classic T2C	WB VTEC Smart T2C	WB VTEC Smart PV T2C
Code	40220	40230	40270
Input Voltage	230 VAC 50/60Hz	230 VAC 50/60Hz	230 VAC 50/60Hz
Max. current/power.	32A / 7.4kW	32A / 7.4kW	32A / 7.4kW
Stand-by power consumption	1,8 W	1,8 W	1,8 W
Recharge	Mode 3 acc. IEC 61851	Mode 3 acc. IEC 61851	Mode 3 acc. IEC 61851
AC output voltage	230 VAC (1P + N + PE)	230 VAC (1P + N + PE)	230 VAC (1P + N + PE)
Exit	1 x Cable 5m Type 2	1 x Cable 5m Type 2	1 x Cable 5m Type 2
Leakage current circuit >6mA	Not available	On request	On request
Electrical protections	Not included	Not included	Not included
Operation	Plug&Charge	Via app	Via app
Output power adjustment	Internal switch	Via app	Via app
Power modulation according to home consumption	Not available	Included (through delivered toroid)	Included (through delivered toroid)
User profile management	Not available	On request	On request
Payment management	Not available	On request	On request
Charging with photovoltaic excess	No	No	Yes

Three phase models
Code	40250
Model	Wallbox VTEC Smart T2TC
Input Voltage	Three-phase 400 VAC
Max. current	32A
Max. power	22 kW
Stand-by consumption	2W
Recharge	Mode 3 acc. IEC 61851
AC output voltage	400 VAC
Exit	1 x Cable 5m T2
Electrical protections	Not included
Operation	Via app
Output power adjustment	Via app
User profile management	On request
Payment management	On request

Is this Wallbox remotely manageable?

The WB VTEC Smart model allows management via app but the wallbox must be connected to the internet via WiFi, or with a SIM card.

Is the Wallbox VTEC Classic available in a three-phase version?

No, just single phase.

Is it possible to adjust the charging power in the Wallbox VTEC Classic?

Yes, via an internal switch.

Which model of the Wallbox VTEC allows dynamic charge adjustment according to household consumption?

The Classic T2CRP model and the single-phase Smart models.

Is this Wallbox enabled for payments?

The WB Prime Smart model allows you to enable credit card payment. Please contact us for more details.

How much power can the Wallbox VTEC deliver?

Wallbox VTEC in single-phase version delivers up to 7.4 kW (32A)

Wallbox VTEC in three-phase version delivers up to 22 kW (32A)
